Ubiquiti
Part no. ES-24-250W-AU
Freight is worked out from your postcode in your list. We confirm stock and delivery before anything is charged.
We need to check the weight and size of this item and confirm delivery options manually.
Mechanical Dimensions 485 × 43.7 × 285.4 mm (19.1 × 1.7 × 11.2 in) Weight 4.7 kg (10.4 lb) Hardware Management Interface (1) RJ45 serial port, Ethernet In/Out-Band Networking Interface (24) GbE RJ45 ports (2) 1G SFP ports PoE Interface (24) PoE/PoE+ 2-pair (Pins 1, 2+; 3, 6-) (24) 24V DC passive PoE 2-pair (Pins 4, 5+; 7, 8-) Total Non-Blocking Throughput 26 Gbps Switching Capacity 52 Gbps Forwarding Rate 38.69 Mpps Power Method 100–240V AC, universal input, 50/60 Hz Power Supply AC/DC, internal, 250W Max. Power Consumption 30W (excludes PoE output) Total PoE Available 250W Max. PoE Wattage per Port (PSE) PoE+: 34.2W Passive PoE: 17W Voltage Range (PoE Mode) PoE+: 50–57V Passive PoE: 20–27V ESD / EMP Protection Air/contact: ±24 kV LEDs Ethernet ports: PoE, speed/link/activity SFP ports: speed/link/activity Button Factory reset Rackmount Yes, 1U Shock and Vibration ETSI 300-019-1.4 standard Operating Temperature -5 to 40 °C (23 to 104 °F) Operating Humidity 5–95% non-condensing Certifications CE, FCC, IC, Anatel (01245-15-08356) NDAA Compliant Yes
